1.2t | AM12 Wonton Edition
1.2t | AM12 Wonton Edition
The AM12 - Wonton Edition!
- 1.2T Mini Excavator with exceptional build config, quality and price!
Features
· Swing Boom
· Hydraulic Thumb
· Expanding Tracks
· KOOP KD192FE Diesel Engine
· Upgraded Pilot Controls and Safety
· Updated Boom Style (Top Mounted Cylinder)
· Upgraded Chassis Size
· Increased Track Width and Length
· Grease Track Tensioning
Package Includes
1x AM12 – Wonton Edition | 1.2t Mini Excavator
1x 1.0t-1.8t - Ripper
1x 1.0t-1.8t - Mechanical Quick Hitch
1x 1.0t-1.8t - 200mm Trenching Bucket
1x 1.0t-1.8t - 400mm Digging Bucket
1x 1.0t-1.8t - 800mm Mud Bucket
*Attachments include 25mm Pins/Bolts.
Machine Configuration
· Hydraulic Cooler with Fan
· Hydraulic Thumb
· Swing Boom
· Updated Boom Style (Top Mounted Cylinder)
· Auxiliary with Flat-face Quick Connectors
· Direct Hydraulic Side Pilot Controls
· Upgraded Control Boxes with Safety Lever (Hydraulic Lock)
· Upgraded (larger) Telescopic Chassis
· Upgraded Track Width & Length (230 x 72 x 41)
· KOOP KD192FE Single Cylinder (Air Cooled - Diesel Engine)
· Grease Track Tensioning
· Hydraulic Cylinder Protectors
· ROPS with Poly Canopy
· Warning / Safety Light
· Bright LED Work light on Boom with Steel Protector
Parameters
Performance |
|
Machine (dry) Weight |
1050kg |
Operating Weight |
1200kg |
Digging Bucket Capacity |
0.022cbm |
Digging Bucket Width |
400mm |
Engine |
KOOP(KD192FE) |
Rated Power |
7.6kw/3600r/min |
Displacement |
0.211 L |
Main Pump |
SHIMADZU |
Main Specifications |
|
Overall Dimensions (LxWxH) |
2870x930x2285 mm |
Wheelbase |
770mm |
Track Width |
230mm |
Overall Range |
|
Max. Digging Height |
1745mm |
Max. Unloading Height |
1725mm |
Max. Digging Depth |
1655mm |
Max. Digging Distance |
1490mm |
Max. Digging Height |
1745mm |
Max. Unloading Height |
1725mm |
Product Description
Introducing the AM12 – Dumpling Edition | 1.2t Mini Excavator, a compact powerhouse designed for efficiency and precision. With a machine-only price of $15,490.00 inc. GST and a package price of $16,490.00 inc. GST, this mini excavator offers exceptional value with its robust features and reliable performance.
The AM12 is equipped with a swing boom that enhances manoeuvrability, allowing operators to pivot the arm for precise digging and loading in confined spaces. The hydraulic thumb feature offers a secure grip for handling materials, enhancing efficiency and safety on the job site. Expanding tracks give the excavator the ability to adapt to various terrains, ensuring stability and traction in challenging conditions.
At its core, the AM12 boasts a KOOP KD192FE Diesel Engine, known for its durability and power. This engine is designed to handle demanding tasks with ease while providing fuel efficiency. Upgraded pilot controls and safety features ensure precise operation and peace of mind, allowing operators to focus on the task at hand.
The excavator’s updated boom style with a top-mounted cylinder provides an extended reach for digging deeper and accessing hard-to-reach areas. An upgraded chassis size contributes to the machine’s stability and durability, ensuring it can withstand heavy use. Additionally, the increased track width and length offer smooth movement and improved weight distribution.
The AM12 also simplifies maintenance with its grease track tensioning system, making it easy to adjust and maintain optimal track tension. This feature, along with the excavator’s other advanced capabilities, makes the AM12 – Dumpling Edition a smart investment for businesses looking to enhance their operational efficiency and productivity. Choose the AM12 for a reliable and versatile mini excavator that’s ready to tackle any challenge.
