Fitment and part numbers
Oil Filter - KOOP KD192F suits the AM10 1.0T Mini Excavator and AM12 1.2T Mini Excavator (KOOP KD192F / KD192FE engine). Stocked locally in Derwent Park, Tasmania.
Not sure it is the right part? Send us a photo of the part or your machine's serial plate and we will confirm the match before you order. Ask about fitment
Part details
| Our SKU | AM-PRT-GEN-OFL |
|---|---|
| Filter type | Oil |
| System | Filters & Routine Maintenance |
Genuine replacement engine oil filter for the KOOP KD192F single-cylinder diesel engine (AM10, AM12 mini excavators). Spin-on style with bypass valve — keeps engine oil clean and protects critical engine components.
Specifications
- Engine: KOOP KD192F (single-cylinder, air-cooled diesel)
- Type: Spin-on oil filter with anti-drainback valve
- Capacity: 0.6–0.8 litre (check engine manual for exact requirement)
- Bypass Valve Setting: 2.0 bar (opens if filter clogs to prevent oil starvation)
- Thread Size: M18 × 1.5 (standard spin-on)
- Compliance: ISO 4572 oil filter standard
Compatibility
Fits: AM10 1.0T & AM12 1.2T mini excavators (KOOP KD192F/KD192FE engines)
Also Compatible: Other 1.0T–1.2T compact excavators using KOOP KD192F engines
Engine Specs: Single-cylinder, 7–7.5 kW @ 3000 rpm, air-cooled diesel
Maintenance Schedule
- Replacement Interval: Every 250 operating hours OR annually (whichever comes first)
- Heavy-Use Environments: Every 150–200 hours if operating in dusty or high-temperature zones
- Signs of Wear: Pressure warning light on dash, dark/dirty oil appearance, engine noise (knocking/ticking)
Installation Notes
- Engine must be warm but OFF before filter replacement (warm oil drains better)
- Use oil filter wrench to unscrew old filter (turn 3/4 turn after seal contacts)
- Drain remaining oil into pan (may drip ~0.5 litre)
- Wipe new filter gasket area on engine with clean cloth
- Apply thin layer of fresh oil to rubber gasket on new filter
- Hand-tighten new filter until gasket contacts, then turn 3/4 more (do NOT over-tighten)
- Start engine and check for leaks around filter seal
- Re-check oil level after 5-minute warm-up and top up if needed
Related Products
Service Kit (AM10/AM12): Pair with Air Filter (KD192F), Fuel Filter (KD192F), and hydraulic fluid for complete scheduled maintenance
Australia-wide delivery available. Freight is calculated at checkout from size and weight.
Parts and filters ship Australia-wide. Freight is calculated at checkout from size and weight. Bulky items such as engines, cylinders, tracks and hydraulic motors are click-and-collect from Derwent Park at checkout; ask us for a freight quote if you cannot collect.
Free pickup from Derwent Park. We hold stock locally rather than drop-shipping from overseas, so most parts leave the same week.
How do I know this part fits my machine?
Every listing states the machine or engine it suits. If you are unsure, send us a photo of the part or your machine's serial plate and we will confirm the match before you order.
Which engine does my machine run?
The KOOP KD192F and Laidong KM385 are the engines fitted across the AM10, AM12 and AM16 machines. A photo of the serial plate is the quickest way to confirm which one you have.
Are wear parts covered by warranty?
Wear parts such as teeth, pins, bushings and cutting edges are excluded from warranty by nature, so we keep them stocked and priced to be replaced rather than nursed.
Do you stock this locally?
We hold stock in Derwent Park, Tasmania, rather than drop-shipping from overseas, so most parts leave the same week.
